3 Axis Brushless Gimbal Frame Storm32 Controller Spare Parts Accessories Part for Gopro 3 SJ4000
Drone Spark
Regular price
$130.99
$304.99
3 Axis Brushless Gimbal Frame Storm32 Controller Spare Parts Accessories Part for Gopro 3 SJ4000
Control panel:A new generation of 32-bit brushless pan/tilt control board, non-Alexmos hair version.
Performance parameter:(1) With the STM32F103RC at 72 MHz processor, the processing speed is 10 times faster than that of the 8th, and the response is faster and more sensitive. (2) It can be equipped with onboard Bluetooth, PID tuning via mobile phone, and convenient outdoor tuning. (3) On-board gyroscope and acceleration sensor (MPU6050), dual gyroscopes, can achieve more actions
(4) Infrared led interface, remote camera is more convenient. (5) Futaba S-Bus, support bus receiver: Spektrum satellite port. (6) Up to 7 channels of PWM/Sum-PPM input/output. (7) Each axis can be connected to support the analog joystick, and the SLR handheld pan/tilt can use this function.(8) With an additional I2C port (I2C#2), an external 6050 can be used instead of the onboard sensor.
(9) 3 aux interfaces. (10) Power supply voltage: 6 18 V or 2 4S.(11) Motor drive current: 2A per phase per motor
(12) Dimensions: 5 cm x 5 cm, Ø3 mm screw holes, hole spacing 45 mm. (13) Weight: 13 g
specification
Motor model: 2206/100T brushless motor: 2, 2804/100T brushless motor: 1
Driver board: STORM32BGC
Firmware version: o323bgc-release-v070
Hardware version: V130
Working voltage: 3-4S (11.1-16.8V)
Working current: 350mA
Joystick control angle: PITCH: -25 degrees +25 degrees / ROLL: -25 degrees +25 degrees / YAW: -90 degrees + 90 degrees.
Switch control mode: lock / follow
Size: 80 * 80 * 100mm (L * W * H)
Weight: 180g
Scope of application: GOPRO series compatible cameras.
Power connector: JST and HX
Instructions for use
Install the camera (must install the camera, otherwise it will keep shaking), after the power is turned on, stabilize the gimbal for about 20 seconds (do not shake the gimbal, keep the gimpit hanging, off the ground), after hearing a sound, you can use it normally.
Can control pitch through receiver or other separate PWM channels
Can set follow mode or lock mode
Colour: Black
Material: Alloy
Package Contents:
1 set * Storm 32 parts Accessories part
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
