Eachine Tyro69 105mm F4 OSD 2.5 Inch 2-3S DIY FPV Racing Drone PNP w/ Caddx Beetle V2 1200TVL Camera
Notice:
1. This is the DIY version that comes unassembled.
2. Comes without battery, charger, receiver or radio transmitter.
Specification:
Brand Name: Eachine
Model: Tyro69
Item Name: 2.5 Inch DIY FPV Racing Drone
Version: PNP ( Without Receiver, Battery and Radio Transmitter)
Drone Wheelbase: 105mm
Arm Plate Thickness: 2mm
Max. Propeller: 2.5 Inch
Material: 3K Carbon Fiber & 3D Printed TPU Parts
Weight: 47.9g ( without battery)
| Eachine F411 OSD Flight Controller |
Main control chip: STM32F411 IMU: MPU6000
Integrated Betaflight OSD SBUS/ IBUS/ for DSMX / UART Shared: UART1-RX BEC: 5V 2AWS2812 Led Strip : Yes
Beeper : Yes |
| Eachine 20A BL_S 4In1 ESC |
MCU:48MHz EFM8BB21F16G Input Voltage: 2-6S Con. Current: 20A Burst Current: 25A (10S) BEC: NO Size: 28.7x30.7mm Mounting Hole: 20x20mm Weight: 24g Support DShot150/300/600, PWM, OneShot125, OneShot42, MultiShot ( DShot600 in default out from factory) |
| Eachine 1104 8600KV 2-3S Motor |
KV: 8600KV Lipo cell: 2-3S
Weight: 4.3g |
| 65mm 2-Blade Propeller |
Item Name: 65mm 2-Blade Propeller Shaft: 1.5mm Quantity: 10 CW & 10 CCW Color: Transparent Black / Black/ Red ( Sends Randomly ) |
| Caddx Beetle V2 Camera AIO VTX |
Output po wer: 25mW Channel: 48CH Input Voltage: 2.9-5.5V Support SmartAudio VTX Size: 15x14mm |
|
Image Sensor: 1/3 CMOS Horizontal Resolution: 1200 TVL TV System: PAL Image: 4:3 Lens: 2.1mm Dimensions: 14x14x16mm Weight: 4.1g (Camera + VTX) |
|
| Recommend Lipo Battery ( Not Included) | Recommend 3S 350-450mAh Lipo Battery |
Package Included:
1x Eachine Tyro69 DIY FPV Racing Drone
