(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery
(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery
(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery
(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery
(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery

(In Stock)New Arrival Eachine EV800 5 Inches 800x480 FPV Goggles 5.8G 40CH Raceband Auto-Searching Build In Battery

Drone Spark

Regular price $794.99 $1,854.99 Sale


aeProduct.getSubject()
Note: The goggles upgraded version with the face sponge and  AV IN function . The Headphone jack was changed to 3.5mm. The total weigh reduction of 26g.


Specification

Brand name

Eachine
Item No.

EV800
Screen
Screen size: 5.0 inch
Screen resolution: 800*480 (No blur after enlarge by the lens)
Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV
View Angle: 140/120 degree(Horizontal/Vertical)


Lens
3x boost of the video to acquire intense feel-in-there video;
92% transparent rate no distort of light;


Battery and recharge
Built-in 3.7V/2000mAh battery;
Each battery circle offer around 3.5hr working time;
5-12V wide recharging voltage range, typical recharging voltage is 5V
Accepts 5V power banks or 2S(7.4V)/3S(11.1V) battery as back-up power to have long working time


Receiver
Build in 5.8G 40CH Raceband receive

                                                  Frequency Table
Frequency Band A 5865 5845 5825 5805 5785 5765 5745 5725
Frequency Band B 5733 5752 5771 5790 5809 5828 5847 5866
Frequency Band E 5705 5685 5665 5645 5885 5905 5925 5945
Frequency Band F 5740 5760 5780 5800 5820 5840 5860 5880
Frequency Band R 5658 5695 5732 5769 5806 5843 5880 5917
Body
Dimension: 180x145x82mm
Weight: 349g with 3.5hr 2000mAh battery
Belt: three-ways adjustable belt




Feature:
- With comfortable face sponge and AV IN function;
Separable design, 5 inch screen can be used as small monitor on radio controller or with tripod;
- HD high brightness 5inch LCD specially tuned for FPV racing;
- Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
- Come with advanced auto-searching function ad show you the working frequency on screen;
Built-in 3.7V/2000mAh battery, each full charge revive around 3.5hours working time;
- Wide range re-charge voltage 5-12V, power banks or 2S/3S batteries can be used as back-up power sour, to prolong the working time;
- Ergonomic design fit your faces;
- Super-wide visible angle up to 82 degree;
- 92% transparent lens adopted, no distort, no blur on the adage of screen;
- Light weight 375g with 3.5hr 2000mAh battery, RTF for any scale racing game.
- 5 inch 800*480px HD high brightness LCD

Package Included:
1 X EV800 FPV VR Goggles (Built-in 3.7V/2000mAh battery)
1 X Mushroom Antenna
1 X USB charger cable
1 X Battery charger cable
1 X AV IN cable
1 X User Manual
1 X Clean cloth
1 X Bag
