Smart Car Robot E18-D80NK Infrared Obstacle Avoidance Photoelectric Sensor Proximity Switch 3-80cm Detection Range Adjust

Product Introduction


   E18-D80NK is a set of transmitter and receiver in one of the photoelectric sensor. Detection distance can be adjusted according to requirements. The sensor has many advantages such as long distance detection, low visible light interference, cheap price, easy assembly, and easy to use. It can be widely used in robot obstacle avoidance, pipeline line piece and many other automation products.



Product Application


1. Automatic production line of goods counting equipment
2. Multi-function reminder
3. Take the maze robot
Technical Parameters:
1. Output Current DC / SCR / Relay Output: 100mA / 5V power supply
2. Current consumption DC <25mA
3. Response time <2ms
4. Pointing angle: ≤ 15 °, the effective distance 3-80 CM adjustable
5. Detection of objects: transparent or opaque body
6. Working temperature: -25°C ~ +55 °C
7. Standard detection object: the following incandescent 3000LX below 10000LX sunlight
8. Housing material: plastic

Electrical Characteristics:

  • Sensing range: 3-80cm

  • Sensing object: Translucency, opaque

  • Supply voltage: DC5V

  • Output operation: Normally open (O)

  • Output: DC three-wire system (NPN)

Pin Definitions:

  • Red -> positive

  • Black ----> signal

  • Blue -> negative

​

Shipping list



  •  Infrared Obstacle Avoidance Photoelectric Sensor: 1pcs

​

Product Pictures



HTB1JHJKNVXXXXcFXFXXq6xXFXXX0HTB1xCNRNVXXXXcVXpXXq6xXFXXXsHTB1yDXQNVXXXXcuXpXXq6xXFXXXcHTB14.0CNVXXXXcyXVXXq6xXFXXXr

Warm Prompt



1. Due to computer monitor and the actual shooting brightness and other reasons, there will be a certain color difference.
The final color please refer to our actual goods. Please know this before you buy it. Thank you !
2. The picture we show is 100% Real Object Photography.
3. The size may have 2-3cm differs due to the maunal measurement.
4. For  the shipping convenience, the product is unassembled.
