5V-24V Controlled Switch RC Car Lights RC Receiver Controlled Switch 4 Types Available For RC Model Car Truck Toys Accessories

EL0003727

Specification:

• 100% brand new with high quality

• Type: High-current version, Single-channel version, Two-channel version, Four-channel version

• Plug into the receiver's CH3 socket, and you will be able to control the car light via the CH3 of the remote receiver.

• The single-channel control version and the high-current version are simple switches, without flashing and BLN Control functions.

• Single-channel and two-channel version: Max load: 5V 1A

• High-current version: Input voltage: 5V-24V, current: 5A Inrush current: 10A

• Four-channel version: Input voltage: 5V-24V, max load of each single channel is 3A

Functions:

• Single-channel version: On -- Off -- On -- Off...

• Two-channel version: two channels output light up at the same time -- Channel A lights on, and Channel B turns off -- Channel A turns off, and Channel B lights on -- 2 channels flashing one by one -- 2 channels flashing at the same time -- 2 Channels BLN lighting effect -- (move in circle)

• High-current version: On -- Off -- On -- Off...

• Four channel version: Horse race lamp mode -- 4 channels flashing one by one -- Channel 1 & 3, Channel 2 & 4 Flashing one by one -- 4 channels flashing at the same time -- 4 channels light up at the same time -- 4 Channels BLN Mode -- Channel 1 and Channel 3 light up, and the other 2 channels turns off -- Channel 2 and Channel 4 light up, and the other 2 chancels turns off -- Channel 1 and Channel 4 light up, and the other 2 channels turns off -- Channel 2 and channel 3 light up, and the other 2 channels turn off -- Channel 1 and channel 2 light up, and the other 2 channels turn off -- Channel 3 and Channel 4 light up, and the other 2 channels turn off -- 4 Channels all turn off ... (move in circle)

Package Included:

• 1 x RC Receiver Controlled Switch

Note:

• Please allow minor error due to manual measurement.

• The colors may be a little difference for the different monitor display.
