Emax 2S Tinyhawk S FPV Racing Drone Kit With Camera 0802 15500KV Brushless Motor Support 1/2S Battery RC Plane

Emax On-Board Receiver Number of Channels: Up to 8CH using SBUS Compatibility: FrSky D8 mode The receiver is programmed into the main flight controller MCU via betaflight. The bind procedure is similar and different settings can be changed in betaflight if desired. Binding Procedure Binding is the process of uniquely associating a receiver to a transmitter module. A transmitter module can be bound to multiple receivers (not to be used simultaneously). A receiver can only be bound to one transmitter module. 1.Hold the bind button for 2 seconds while the flight controller is already on. When the RED LED is flashing, it means the receiver is in BIND MODE 2.Turn on the transmitter, make sure it is set to D8 mode, and then set it into bind mode. When the BLUE LED on the flight controller starts flashing, it means bind successful. 3.Power cycle the flight controller and take your radio out of bind mode.
