F4 OSD Flight Controller |
Brand Name: LDARC
Firmware: MATEKF411
MCU: STM32F4AA
MPU: MPU6000
BEC: 5V 1.5A
Onboard Current Sensor
Onboard ESC
Support SBUS DSM2/X iBUS Receiver |
|
Onboard 12A BLheli_S ( G_H_30) 4in1 ESC |
Con. Current: 12A
Max. Current: 20A
Support 2-4S Lipo
Firmware: BLheli_S |
|
Onboard AC2000 Receiver ( Only BNF Version has) |
Item Name: AC2000 Receiver
Rated voltage: 4.0V~6.0V
Support S-FHSS(8 CHs)/D16 non-EU(14 CHs)/D16 EU-LBT(14 CHs) three modes, output S.BUS signal
Perfect fit high reliability medium and small size drone
The channel 16 of S.BUS value is real-time RSSI, BETAFLIGHT OSD can display this RSSI value in screen.
|
|
48CH 0/25/100/200mW VTX |
Brand Name: LDARC
Channel: 40CH
Power: 0/25/100/200mW Switchable
Input Votlage: 2-4S
Support IRC Tramp |
|
51mm 3-Blade Propeller |
Brand Name: LDARC
Item Name: 51mm 3-Blade Propeller
Color: Black
Quantity: 10 CW & 10 CCW |
|
XT1102 9300KV Motor
|
Brand Name: LDARC
Model: XT1102
Item Name: 1103 9300KV
Shaft Diameter: 1.5mm
Input Voltage: 2-3S
Motor Mounting Hole Size: 6.6 ( M1.4)
Weight: 2.8g
|
|
Runcam Nano 2 700TVL Camera
|
Brand name: Runcam
Model: Nano 2
Image Sensor: 1/3" CMOS
Horizontal Resolution: 700TVL
Lens: 2.1mm(M8) FOV 155°
Signal System: NTSC / PAL
S/N Ratio: >50dB
Electronic Shutter Speed: Auto
Auto Gain Control (AGC): Auto
Min. Illumination: 0.01Lux@1.2F
D-WDR: Auto
Day/Night: Color
Power: DC 3-5.5V
Current : 110mA@5V 120mA@3.3V
Housing Material: ABS
Net Weight: 3.2g
Dimensions: L14mm*W14mm*H16mm
|
|
Lipo Battery ( All Version Have) |
3S 11.4V 300mAh 30C Lipo Battery
|
