Socket 1: Left Signal Light(yelow)
Socket 2: Front Upper Light(white)
Socket 3: Front Lower Light(white)
Socket 4: Right Signal Light(yellow)
Socket 5: Backward Light(hite)
Socket 6: Brake Light(red)
Socket 7: Turn ON Status/Simultaneous with Socket2
Turn OFF Status/lt always lighted
Socket 8: Turn ON Status/Simultaneous with Socket 6
Turn OFF Status/ lt always lighted
Channel 1 Socket: Use Y-Cable to connect the Steering Servo and Receiver to LED System control box
Channel 2 Socket: Use Y-Cable to connect the ESC or Throttle Servo and receiver to LED System control Box
REV1: RC CH1 Steering Signal Reverse
REV2: RC CH2 Throttle Signal Reverse
