Drone Spark

Regular price $112.99 $261.99 Sale

详情页1





产品描述



★5 INCH FRAME KIT THICKNESS JUST RIGHT-The Bottom Plate Of The Martian II is 2mm thick and the Top Plate is 1.5mm thick.

★NEW UNOPENED 5 INCH DRONE FRAME KIT-The new unopened frame kit refuses to send used items, so you can buy them with confidence.

★100% CARBON FIBER SHEET-Carbon plate with pure 3K twill carbon fiber sheet.

★100% NEW-Produced By TCMM,Well made and durable.

suggested Lipo is a 1550mah&2300mah 3 or 4s.

Support for 32mm board cams as well as HS1177.

Support to carry HD camera (Such as the GoPro 4, runcam 2, or GoPro Session) .



Recommend parts (package not include):

ESC: 12A-20A

Propeller: 5030 5045

Battery: 3S 1500-2200

Flight control: CC3D   NAZE32  F3

Motor: 1806  2204  2205  2206


产品参数



Specification:

Brand name

TCMMRC

Item name

Martian II

Material

3K carbon fiber matte

Wheelbase

220 mm

Motor hole position

M3x16x16mm M3x19x19mm

Flight control hole position

M3x30.5x30.5mm

Camera hole position

M3x28x28mm

Space height

28mm

Paddle

5 inches

Arm thickness

4mm

Upper board

2mm

Rack net weight

175.2g



产品包装

*Send item according to the product attribute of your choice

1x 220mm 4pcs 4mm Arm Kit includes:only 220mm 4pcs 4mm Arm Kit

1x Martian II Accessories Kit includes:only Martian II Accessories Kit

1x FPV Racing Drone Frame Kit includes:

1x Iron screw package: M3*6mm-18pcs, M3*8mm-6pcs, M3*12mm-20pcs, M3 silver nut 12pcs.

1x Aluminum column package: Mesh purple M3*35mm-8pcs,Bright purple M3*3mm-3pcs.

1x Power distribution board.

1x XT60 plug.

1x Isolation column package.

1x Sponge mats.

1x Nylon cable tie.

​1x Battery tie.

1x Camera protector seat(color sent randomly).
